| Part# | AFB0924VH |
| Category | Fans, Blowers, Thermal Management |
| Fans | |
| DC Brushless Fans (BLDC) | |
| Mfr | / |
| Series | AFB |
| Packaging | Box |
| Part Status | Active |
| Voltage - Rated | 24VDC |
| Size / Dimension | Square - 92mm L x 92mm H |
| Width | 25.40mm |
| Air Flow | 67.8 CFM (1.90m³/min) |
| Static Pressure | 0.302 in H2O (75.2 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Protection |
| Noise | 45.0dB(A) |
| Power (Watts) | 5.28 W |
| RPM | 3800 RPM |
| Termination | 2 Wire Leads |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Approval Agency | CE, CSA, UL, VDE |
| Weight | 0.218 lb (98.88 g) |
| Current Rating (Amps) | 0.220A |
| Voltage Range | 14 ~ 27.6VDC |
| Material - Frame | Plastic |
| Material - Blade | Plastic |
| Lifetime @ Temp. | 70000 Hrs @ 40°C |
| Base Product Number | AFB0924 |
