Product Descriptions

The XL6012 regulator is a wide input range, current mode, DC/DC converter which is can be configured as either a boost, flyback, SEPIC or inverting converter. The XL6012 built in high voltage N-channel power MOSFET and fixed frequency oscillator, current-mode architecture results in stable operation over a wide range of supply and output voltages.

The XL6012 regulator is special design for portable electronic equipment applications.

Product Features

 Wide 5V to 40V Input Voltage Range

 Maximum Boost Output Up to 60V

 Current Mode Control Provides Excellent

Transient Response

 1.25V reference adjustable version

 Fixed 180KHz Switching Frequency

 Maximum 5A Switching Current

 SW PIN Built in Over Voltage Protection

 Excellent line and load regulation

 EN PIN TTL shutdown capability

 Internal Optimize Power MOSFET

 High efficiency up to 94 PERCENT

 Built in Frequency Compensation

 Built in Soft-Start Function

 Built in Thermal Shutdown Function

 Built in Current Limit Function

 Available in TO220-5L package

Product Applications

 EPC / Notebook Car Adapter

 Automotive and Industrial Boost / Buck-Boost/ Inverting Converters

 Portable Electronic Equipment

Specifications
