NCE60R180T TO247 High voltage N-channel IGBT field-effect transistor

NCE60R180T

Model:NCE60R180T

Manufacturer:/

Package:TO247

马上购买联系我们

详情

Part#	NCE60R180T
Type：	high-voltage N-channel IGBT field-effect transistor
Manufactor	/
DC	NEW
Describe	TO247
Supplier Device Packaging	REEL

TO247

NCE60R180T

NCE60R180T 2

NCE60R180T 3

NCE60R180T 4

NCE60R180T 5

NCE60R180T 6

NCE60R180T 7
