Product Details
W25Q128JVSIM Overview
Non-Volatile is its memory type. It is available in a case with a Tube shape. As you can see, it is embedded in 8-SOIC (0.209, 5.30mm Width) case. There is an 128Mb 16M x 8 memory capacity on the chip. In this device, the memory is of the FLASH-format, which is a popular format in the mainstream computing sector. Due to its extended operating temperature range, the device is well suited for a wide range of demanding applications. A voltage of 2.7V~3.6V is possible to be applied to the supply. There is a recommendation that Surface Mount mounting type should be used for this product. As you can see from the diagram, the chip is planted with 8 terminations. In total, 1 functions are supported by this part. The memory device designed for this application has been designed to be powered by an 3.3V power supply. With a clock frequency of 133MHz, the memory rotates on its own. While this memory chip features many merits, it also offers IT ALSO OPERATES AT 104 MHZ CLOCK FREQUENCY AT 2.7 TO 3.0 V SUPPLY VOLTAGE for improving system performance. Among the SpiFlash® series of memory devices, this part is essential for its applications. A programming voltage of 3V is needed to alter the state of certain nonvolatile memory arrays.
W25Q128JVSIM Features
Package / Case: 8-SOIC (0.209, 5.30mm Width)
Additional Feature:IT ALSO OPERATES AT 104 MHZ CLOCK FREQUENCY AT 2.7 TO 3.0 V SUPPLY VOLTAGE
W25Q128JVSIM Applications
There are a lot of Winbond Electronics
W25Q128JVSIM Memory applications.
telecommunications
workstations,
DVD disk buffer
data buffer
nonvolatile BIOS memory
Camcorders
embedded logic
eDRAM
graphics card
hard disk drive (HDD)
Product Description
Winbond Electronics W25Q128JVSIM
Memory IC SpiFlash® Memory IC SpiFlash® Memory IC SpiFlash® Series 5.23mm mm
Product Attributes
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Memory | |
| Memory | |
| Mfr | Winbond Electronics |
| Series | SpiFlash庐 |
| Package | Tube |
| Product Status | Active |
| DigiKey Programmable | Verified |
| Memory Type | Non-Volatile |
| Memory Format | FLASH |
| Technology | FLASH - NOR |
| Memory Size | 128Mbit |
| Memory Organization | 16M x 8 |
| Memory Interface | SPI - Quad I/O, QPI, DTR |
| Clock Frequency | 133 MHz |
| Write Cycle Time - Word, Page | 3ms |
| Voltage - Supply | 2.7V ~ 3.6V |
| Operating Temperature | -40掳C ~ 85掳C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.209", 5.30mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | W25Q128 |
