| General Description The CD4043BC are quad cross-couple 3-STATE CMOS NOR latches, and the CD4044BC are quad cross-couple 3-STATE CMOS NAND latches. Each latch has a separate Q output and individual SET and RESET inputs. There is a common 3-STATE ENABLE input for all four latches. A logic “1” on the ENABLE input connects the latch states to the Q outputs. A logic “0” on the ENABLE input disconnects the latch states from the Q outputs resulting in an open circuit condition on the Q output. The 3-STATE feature allows common bussing of the outputs. Features ■ Wide supply voltage range: 3V to 15V ■ Low power: 100 nW (typ.) ■ High noise immunity: 0.45 VDD (typ.) ■ Separate SET and RESET inputs for each latch ■ NOR and NAND configuration ■ 3-STATE output with common output enable Applications • Multiple bus storage • Strobed register • Four bits of independent storage with output enable • General digital logic |
Product Description
| TYPE | DESCRIPTION |
| ANSC PART# | ANSC- CD4044BF |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Latches | |
| Mfr | Original |
| Series | 4000B |
| Packaging | Tube |
| Part Status | Active |
| Logic Type | S-R Latch |
| Circuit | 4:04 |
| Output Type | Tri-State, Non-Inverted |
| Voltage - Supply | 3V ~ 18V |
| Independent Circuits | 1 |
| Delay Time - Propagation | 50ns |
| Current - Output High, Low | 6.8mA, 6.8mA |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 16-CDIP |
