| Description The HCPL-22XX, HCPL-02XX, and HCNW22XX are optically-coupled logic gates. The HCPL-22XX, and HCPL-02XX contain a GaAsP LED while the HCNW22XX contains an AlGaAs LED. The detectors have totem pole output stages and optical receiver input stages with built-in Schmitt triggers to provide logic-compatible waveforms, eliminat ing the need for additional waveshaping. Features • 10 kV/µs minimum Common Mode Rejection (CMR) at VCM = 1000 V (HCPL-2211/2212/0211/2232,HCNW2211) • Wide operating VCC range: 4.5 to 20 Volts • 300 ns propagation delay guaranteed over the full temperature range • 5 Mbd typical signal rate • Low input current (1.6 mA to 1.8 mA) • Hysteresis • Totem pole output (no pullup resistor required) • Available in 8-Pin DIP, SOIC-8, widebody packages • Guaranteed performance from -40°C to 85°C • Safety approval – UL recognized -3750 V rms for 1 minute (5000V rms for 1 minute for HCNW22XX) per UL1577 – CSAapproved – IEC/EN/DIN EN 60747-5-2 approved with VIORM = 630 V peak (HCPL-2211/2212 Option 060 only) and V IORM = 1414 V peak (HCNW22XX only) • MIL-PRF-38534 hermetic version available (HCPL-52XX/62XX) Applications • Isolation of high speed logic systems • Computer-peripheral interfaces • Microprocessor system interfaces • Ground loop elimination • Pulse transformer replacement • High speed line receiver • Power control systems |
Product Description
| Type | Description |
| ANSC PART# | ANSC- HCPL-0201 |
| Category | Isolators |
| Optocouplers, Optoisolators | |
| Logic Output Optoisolators | |
| Manufacturer | Original |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Channels | 1 |
| Inputs - Side 1/Side 2 | 1/0 |
| Voltage - Isolation | 3750Vrms |
| Common Mode Transient Immunity (Min) | 1kV/µs |
| Input Type | DC |
| Output Type | Push-Pull, Totem Pole |
| Current - Output / Channel | 25 mA |
| Data Rate | 5MBd |
| Propagation Delay tpLH / tpHL (Max) | 300ns, 300ns |
| Rise / Fall Time (Typ) | 30ns, 7ns |
| Voltage - Forward (Vf) (Typ) | 1.5V |
| Current - DC Forward (If) (Max) | 10mA |
| Voltage - Supply | 4.5V ~ 20V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SO Tall |
| Base Product Number | HCPL-0201 |
