Product Comparison of Parameters

Product Descriptions

The ESP32-WRO0M-32 WiFi module core processor ESP32-WRO0M-32 provides a complete set of 802.11 b/g/n/e/i wireless local area network (WLAN) and Bluetooth 4.2 solutions with small physical size. This chip is designed specifically for low-power and mobile consumer electronics devices, wearable and IoT devices, and integrates all the functions of WLAN and Bluetooth on the chip, with the characteristic of low-cost layout. ESP32-WRO0M-32 also provides an open platform that allows users to flexibly customize features for different application scenarios.

ESP32-WRO0M-32 Function Block Diagram

ESP32-WRO0M-32 is a WiFi and Bluetooth system on chip (SoC) with industry-leading RF performance, low power consumption, and high integration advantages. The ESP32-WR00M-32 integrates complete RF transmission/reception functions, including antenna switches, RF baluns, power amplifiers, low-noise amplifiers, filters, power management modules, and advanced self calibration circuits. The self calibration circuit achieves dynamic automatic adjustment to eliminate defects in external circuits. ESP32-WR00M-32 is equipped with 2 32-bit, LX6 CPUs, with a clock speed of up to 240MHz, and adopts a 7-stage pipeline architecture. ESP32-WR00M-32 also integrates rich analog sensing and digital interfaces.

The ultra-low power RF architecture and patented power-saving technology of ESP32-WRO0M-32 extend the battery life of practical applications.

ESP32-WRO0M-32 fully complies with WiFi 802.11b/g/n/e/i and Bluetooth 4.2 standards, integrates WiFi/Bluetooth/BLE RF and low-power technology, and supports an open real-time operating system RTOS. The adjustment cache integrated in ESP32-WRO0M-32 helps improve system performance and optimize system storage. The flexible RAM/ROM partitioning architecture allows users to customize to meet special requirements and usage scenarios.

ESP32-WRO0M-32 can be used as a standalone application or as a slave device for the host MCU. As a slave device, ESP32-WRO0M-32 provides WiFi and Bluetooth functionality through SPI/SD10 or I2C/UART interfaces.

Product Features

2.1 WiFi.1WiFi

· 802.11 b/g/n/e/i

· 802.11 n (2.4 GHz), with speeds up to 150 Mbps

· 802.11e: Implementing Wireless Multimedia Technology with QoS Mechanism

. WMM-PS, UAPSD

· A-MPDU and A-MSDU frame aggregation technology

· Block reply

· Sharding and restructuring

· Beacon automatic monitoring/scanning

· 802.11i security features: pre authentication and TSN

· Support WPA/WPA2/WPA2 Enterprise/WPS encryption

· Infrastructure BSS Station Mode/SoftAP Mode

· Wi Fi Direct (P2P), P2P discovery, P2P PG style, and P2P power management

· UMA compatibility and certification

· Antenna Diversity and Selection

2.2 Bluetooth

✹ Bluetooth v4.2 complete standard, including traditional Bluetooth (BR/ADR) and low-power Bluetooth (BLE)

✹ Supports standard Class-1, Class-2, and Class-3 without the need for an external power amplifier

✹ Enhanced power control

✹ Output power up to 10dBm

✹The NZIF receiver has a BLE receiving sensitivity of -98dBm

✹ Adaptive Frequency Hopping (AFH)

✹Standard HCI based on SDI0/SPI/UART interface

✹High speed UARHCI with a speed of up to 4Mbps

✹ Supports BT4.2 controller and host protocol stack

✹Service Discovery Protocol (SDP)

✹ General Access Application (GAP)

✹ Security Management Protocol (SMP)

✹ Low power Bluetooth

✹ATT /GATT

✹HID

✹ Supports all low-power Bluetooth applications based on GATT

✹SPP Like Low Power Bluetooth Data Transmitting Protocol

✹BLEBeacon

✹A2DP/AVRCP/SPP,HSP/HFP.RFCOMM

✹CVSD and SBC audio encoding and decoding algorithms

✹ Bluetooth Piconet and Scatternet

2.3 CPU and Storage

✹Xtensa ® 32-bit LX6 dual core processor with a computing power of up to 600 DMIPS

✹448 KByte ROM

✹520 KByte SRAM

✹ 16 KByte SRAM in RTC

✹ QSPI can connect up to 4 FIash/SRAMs, each with a FlashMax of 16MBytes

✹ Power supply voltage: 2.2V to 3.6V

✹ 2.4 Clock and Timer

✹ Built in 8 MHz oscillator, supports self calibration

✹ Built in RC oscillator, supports self calibration

✹ Supports external crystal oscillators ranging from 2 MHz to 40 MHz

✹ Supports external 32 kHz crystal oscillator for RTC, supports self calibration

✹ 2 timer groups, 4 each including 2 64 bit universal timers and 1 main system watchdog

✹ RTC timer with sub second precision

✹ RTC watchdog

2.5 Peripheral Interface

✹ 12 bit SAR ADC with up to 18 channels

✹ 2 8-bit D/A converters

✹ 10 touch sensors

✹ Temperature sensor

✹ 4 SPI

✹ 2 12S

✹ 2 pieces of 12C

✹ 3 UART

✹ 1 Host SD/eMMC/SDI0

✹ 1 Slave SDl0/SPI

✹ Ethernet MAC interface with dedicated DMA, supporting IEEE1588

✹CAN 2.0

✹IR(TX/RX)

✹ Motor PWM

✹ LEDPWM, up to 16 channels

✹ Hall sensor

✹ Ultra low power pre analog amplifier

2.6 Security mechanism

✹ Supports all security features of IEEE 802.11, including WFA, WPA/WPA2, and WAPI

✹ Safe startup

✹ Flash encryption

✹ 1024 bit 0TP, up to 768 bits available for users

✹ Encryption hardware accelerator:

- AES

- HASH (SHA-2) Library

- RSA

- ECC

- Random Number Generator (RNG)

Product Applications

✹Universal Low Power IoT Sensor Hub

✹Universal low-power IoT recorder

✹Video streaming transmission of cameras

✹0TT TV box/set-top box equipment

✹Music player

-Network music player

-Audio streaming devices

✹Wi Fi toys

-Counter

-Toy anti loss device

✹Wi Fi voice recognition device

✹Earphones

✹Smart socket

✹Home automation

✹Mesh network

✹Industrial wireless control

✹Baby monitor

✹Wearable electronic products

✹Wi Fi location sensing device

✹Security ID label

✹Health and Medical Care

-Sports monitoring and anti loss alarm

-Temperature recorder
