Product Descriptions

Developed and produced based on TELINK TLSR8359 wirelessSOC,E03-2G4M10S is with low volume, low power consumption, high reliability andworking in the 2.4GHz frequency band.It comes with a 32-bit high-performance MCUwith a maximum transmit power of 10dBm.

TLSR8359 is good for hardware OTA upgrade and a variety of start-up switching. which is convenient for product feature introduction and upgrade. It is a pure hardware SoC module, it needs to be programmed by the user.

Product Features

Max power 10dBm, multiple levels configurable;

Global ISM 2.4GHz band;

14 bit ADC and PGA,

6 channel PWM;

One Quadrature decoder (QDEC),

Abundant GPIO;

512KB FLASH,64KB RAM:

1.8~3.6V power supply, 3.3V+ ensures good performance;

Applied in -40~+85℃;

Distance is up to 250m

Product Applications

Retail /Logistics

Private network

Lighthouse

Product Specifications
